Input voltage | 100~240VAC 50/60Hz |
Operation voltage range | 85% to 110% of rated voltage |
Power consumption | 5VA Max. |
Display method | 7-segment digit LED Display Process value (PV): Red color, Set point (SV): Green color |
Sensor type | Thermocouple: K, J, T, E, N, R, S, B, U, L, Txk 3-wire Platinum RTD: Pt100, JPt100 |
Control mode | PID, ON/OFF control or Manual tuning |
Control output | Relay output:(resistive load): SPDT (SPST: 1/16 DIN size), 250VAC, 5A |
Voltage Pulse output: DC 14V, Max. load current 40mA | |
Current output: 4 to 20mADC (Load resistance: Max. 600Ω) | |
Display accuracy | 0.1% of measuring range |
Sampling rate | 500 msec/per scan |
Vibration resistance | 10 to 55Hz, 10m/s2 for 10min, each in X, Y and Z directions |
Shock resistance | Max. 300m/ s2, 3 times in each 3 axes, 6 directions |
Ambient temperature | 0oC ~ +50oC |
Storage temperature | -20oC ~ +65oC |
Relative humidity | 35% ~ 80% (non-condensing) |
Altitude | 2,000m or less |
Installation environment | Installation Category 33, Pollution Degree 2. Conforming to EN61010-1 |
Panel protection level | IP65 |
